ESoPe Platform

ESoPe Platform series offers a number of evaluation boards for ESP32 modules. You can expand the boards with individual interfaces by using optional piggyback modules. In addition, we are happy to offer you suitable sensor modules for your sensors or customer-specific software solutions.

Get in touch with us - we develop a tailor-made solution for you.



Product

Description

SLD_C_W_S3

SLD_C_W_S3 is a display controller board from the ESoPe platform series, based on an Espressif ESP32S3-CPU. It is used to control RGB-LC- displays from Schukat's Smartwin display concept

SLD_C_W_S3 can be used as an evaluation board with prefabricated interfaces and software-libraries, but it is also a series module that is suitable for industrial use.

Highlights:

  • RGB-interface for Schukat Smartwin display-concept
  • IO-port (piggyback-ready)
  • industrial standard
  • WLAN / Bluetooth
  • extensive software library (ready for Slint and LVGL)

ESP32S3_BT817

ESP32S3_BT817 is an evaluation board from the ESoPe Platform series, based on an Espressif ESP32S3-CPU. It is used to control RGB-LC- displays from the family concept.

With optional piggy-back modules, the ESP32S3_BT817 can be extended with various interfaces.

Highlights:

  • RGB-interface for family-display-concept
  • interfaces extensible by piggyback-modules
  • industrial standard
  • WLAN / Bluetooth
  • extensive software library

ESP32S3_BT817_P1

The ESP32S3_BT817_P1 clip-on module is an interface module of the ESoPe Platform series and serves as an extension for the ESP32S3_BT817 system.

We offer alternative interface modules on request

Highlights:

  • PMOD I²C
  • PMOD SPI
  • RS485-interface power
  • LAN-interface
  • class-D audio-amplifier
  • WLAN-antenna
  • industrial standard

ESP32S3_PMOD


The ESP32S3_PMOD module is a standalone interface module from the ESope platform series.

It serves as the basis for various PMOD boards.

Highlights:

  • SPI-, I²C- and UART-PMOD-interface
  • WLAN / Bluetooth
  • long range WLAN-antenna
  • powered over USB
  • industrial standard
  • extensible software library

Sensor-Modules

Customer-specific sensor solutions are available on request. Modules with Melexis sensors are available at our partner Dacom West.

Highlights:
  • individual tailor-made solution
  • customer-specific hardware and software
  • industrial standard
